Chauvin Arnoux CA6536 20GΩ Insulation And Continuity Tester

Description

The Chauvin Arnoux CA8345 is a high-performance, Class A power and energy quality analyzer, also part of the Qualistar+ series. It is a portable and user-friendly instrument designed for inspections and maintenance on industrial and commercial electrical installations.

Key Features

• Continuity testing: It performs continuity measurements with a choice of 200 mA or 20 mA test currents.
• DMM functions: The device also includes digital multimeter (DMM) capabilities for measuring voltage (up to 700 V AC/DC), resistance (up to 999 kΩ), and frequency (up to 800 Hz).
• Display: A large, backlit dual digital display features a logarithmic bar graph for easy viewing, even in poor lighting.
• Robust design: It has a safety rating of 600 V CAT IV and is protected by an IP54 / IK04 casing, offering protection against dust and splashes.
• Adjustable test voltage: The CA6536 offers a variable test voltage from 10 V to 100 V in 1 V increments, providing flexibility for testing sensitive equipment.
• Insulation testing: The insulation resistance measurement range extends to 20 GΩ, while remaining compliant with the IEC 61557 standard up to 2 GΩ.
• Adjustable test voltage: The CA6536 offers a variable test voltage from 10 V to 100 V in 1 V increments, providing flexibility for testing sensitive equipment.
• Insulation testing: The insulation resistance measurement range extends to 20 GΩ, while remaining compliant with the IEC 61557 standard up to 2 GΩ.
