Chauvin Arnoux CA8333 Power Quality Analyser

Description

The Chauvin Arnoux Qualistar+ C.A 8333 (P01160541) is a multifunctional power quality analyser designed for electricians and engineers who need to measure and diagnose power quality in a variety of electrical systems. A successor to the C.A 8331, the C.A 8333 is used for both corrective and preventative maintenance and for performing energy surveys.

Key Features

• Data logging: A 2 GB memory allows for continuous recording of selected parameters for several weeks, with a maximum sampling rate.
• Automatic recognition: The analyser automatically recognizes connected current sensors, and users can mix different types of sensors.
• Display: A full-colour TFT screen allows for easy viewing of results, including waveforms, phasor diagrams, and values.
• Software: The device comes with PAT (Power Analyzer Transfer) software for downloading and analyzing results. It is also compatible with the optional Dataview® software for more advanced analysis and report generation.
• Communication: It includes a USB communication interface for transferring data to a PC.
• Measurement channels: The device is equipped with 4 voltage inputs and 3 current inputs, plus a calculated neutral.
• Safety rating: It is rated for use in demanding applications up to 1000V in CAT III and 600V in CAT IV, in compliance with the IEC 61010 standard.
