Kyoritsu 3552BT Digital Insulation Resistance Tester with Bluetooth, 6 ranges

Description

The Kyoritsu 3552BT is a digital insulation and continuity tester with six test voltage ranges and Bluetooth communication functionality. It is the most advanced model in its series, building on the features of the Kyoritsu 3551 and 3552 with the addition of wireless data transfer.

Key Features

• Bluetooth communication: Connects to a compatible tablet or smartphone via the "KEW Smart Advanced" app, allowing for real-time monitoring and wireless data transfer. This eliminates the need for manual note-taking in the field and simplifies reporting.
• Fast measurement speed: Achieves insulation resistance measurements in as little as 0.5 seconds.
• Six test voltages: Offers a range of selectable test voltages—50V, 100V, 125V, 250V, 500V, and 1000V—for versatile testing applications.
• Internal memory: Can store up to 1,000 sets of measurement data.
• Diagnostic tests: Supports Polarization Index (PI) and Dielectric Absorption Ratio (DAR) diagnostic insulation tests.
• Backlit display: A large, digital LCD with a backlight and an auto-sensing light sensor improves visibility in dimly lit areas.
• Continuity testing: Includes a continuity test function with a "Zero \(\Omega \) adjustment" to compensate for test lead resistance.
• Auto voltage detection: Automatically detects whether the measured voltage is AC or DC when the voltage is 30V or higher.
