Mitutoyo 104-141A Outside Micrometer Interchangeable Anvil, 200 to 300 mm

Description

The Mitutoyo 104-141A Outside Micrometer is an analog measuring instrument with a 200 to 300 mm measuring range. Its interchangeable anvils allow for a broader range of measurements with a single tool. It is primarily used in industrial and manufacturing settings for precise measurement of external diameters.

Key features

• Interchangeable anvils: This micrometer comes with four interchangeable anvils and setting standards, allowing a single instrument to cover a wide measuring range from 200 mm to 300 mm.
• High precision: It offers high accuracy and repeatable measurements thanks to its 0.01 mm graduation and carbide-tipped, micro-lapped spindle and anvil faces.
• Constant force mechanism: The ratchet-stop mechanism ensures that a consistent and precise measuring force is applied during each measurement, which helps eliminate inconsistencies caused by varying pressure.
• Durable construction: The frame is made from high-grade tool steel and features a protective, baked-enamel finish for durability and corrosion resistance.
• Analog display: The metric vernier scale on the thimble and sleeve has a satin chrome finish to resist rust and glare, making it easy to read.
• Secure locking: A spindle lock is included to secure the measurement position once it has been set.
• Storage and accessories: The micrometer is supplied with the interchangeable anvils, setting standards, and a fitted wooden case for safe storage and transport.
