Mitutoyo 104-143A Outside Micrometer Interchangeable Anvil, 400 to 500 mm

Description

The Mitutoyo 104-143A Outside Micrometer is an analog measuring tool designed for taking precise measurements of outside diameters within a range of 400 to 500 mm. It features interchangeable anvils to accommodate different measuring tasks.

Key features

• Interchangeable anvils: The micrometer comes with four interchangeable anvils (0 mm, 25 mm, 50 mm, and 75 mm) to cover a wide measuring range from 400 to 500 mm.
• Ratchet stop: This mechanism provides a constant, pre-set measuring force of 10 to 14 N, ensuring precise and repeatable measurements.
• High-grade construction: Built with a durable frame and high-grade tool steel, the micrometer is designed for long-lasting performance in industrial environments.
• Carbide-tipped measuring faces: The spindle and anvil faces are tipped with carbide and feature a micro-lapped finish, offering resistance to wear and maintaining accuracy over time.
• Clear analog scale: The thimble and sleeve have a satin-chrome finish with a laser-etched scale for easy and quick reading of measurements.
• Zero-setting standards: The micrometer is supplied with four zero-setting standards (400, 425, 450, and 475 mm), allowing for accurate calibration after changing anvils.
• Fitted wooden case: For protection and easy storage and transport, the tool is provided in a fitted wooden case.
• Spindle lock: A locking mechanism on the spindle secures the measurement in place to prevent movement during handling.
