Mitutoyo 126-135 Screw Thread Micrometer Interchangeable Tips, 250 to 275 mm

Description

The Mitutoyo 126-135 Screw Thread Micrometer is an analog micrometer designed to measure the pitch diameter of screw threads within a 250-275 mm range. It is part of the Series 126 of interchangeable anvil screw thread micrometers.

Key features

• Interchangeable tips: The tool can be used with optional, interchangeable V-anvil and conical spindle tip sets to measure metric/unified (60°) or Whitworth (55°) screw threads. These tips are not included and must be purchased separately.
• Constant force mechanism: It is equipped with a ratchet stop to apply a consistent and uniform measuring force, ensuring repeatable results.
• High-grade materials: The interchangeable anvils are made of high-grade steel, which is hardened and precision-ground. The thimble and sleeve have a satin-chrome finish.
• Stable frame: The frame is designed to be highly stable and includes a heat shield to help maintain accuracy during prolonged use.
• Direct reading: The micrometer allows for direct reading of the screw's pitch diameter, eliminating the need for further calculation.
• Accessories: A metric (60°) setting standard is included with the micrometer. It is supplied in a fitted case for protection.
