Mitutoyo 543-851A Digimatic Indicator, ID-F

Description

The Mitutoyo 543-851A Digimatic Indicator, ID-F is a metric, multifunction digital indicator with an Absolute (ABS) linear encoder and a clear, backlit LCD screen that is part of Mitutoyo's Series 543 ID-F line. It offers advanced features such as bidirectional communication with a PC, a Go/±NG judgment function with color-changing display, and selectable resolutions for precise measurements.

Features and benefits

• Absolute (ABS) encoder: The indicator uses Mitutoyo's ABS sensor, which memorizes the origin point. This eliminates the need to reset the origin after powering on and prevents over-speed errors.
• Bi-directional communication: The ID-F series is equipped with a Digimatic S1 interface, allowing for two-way communication with a PC. This not only enables measurement data collection but also lets a PC control the indicator's settings, which can improve work efficiency.
• Go/±NG judgment: For tolerance checking, the indicator's LCD backlight can be set to change from green to red when a measurement falls outside the user-defined tolerance range.
• Large, backlit LCD: The screen features 11mm-high characters, an analog bar, and can be rotated 330° for enhanced visibility and ease of use.
• Multi-functionality: Functions include peak detection (MAX/MIN), runout measurement (MAX - MIN), resolution switching, simple calculation, and a function lock to prevent accidental changes to settings.
• Calibration notification: The indicator can be set to notify the user when its calibration period is approaching, helping with proper gauge management.
